? Speed: 300 Mbps
? Antenna: 2 x 5dBi
? Open Space Coverage: 2000sqft
? User: 10 ~ 25 in 2.4GHz
Interface 4 *10/100Mbps LAN Ports
1 *10/100Mbps WAN Port
Power Supply 9V DC/0.5A
Antenna 2 *5dBi fixed antennas
Button RST·WPS Button, Power ON/OFF Button
LED Indicators 1 *Power, 1 *CPU, 1 *Wireless, 1 *WAN, 4 *LAN
Dimensions(L x W x H) 5.8 x 3.0 x 1.0 in. ( 147.5 x 76 x 25 mm)
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
RF Frequency 2.4~2.4835GHz
Data Rate 802.11n: Up to 300Mbps
802.11g: Up to 54Mbps (dynamic)
802.11b: Up to11Mbps (dynamic)
EIRP < 20dBm
Wireless Security 64/128-bit WEP, WPA/WPA2 Security (AES/TKIP)
Reception Sensitivity 270M: -61dBm@10% PER
135M: -65dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Brand-No Brand
SKU-231217EA163
What's in Box-Only N Router
